Switch settings: SW = 00000000 for full-duplex mode SW= 11000000 for half-duplex mode (default)
External interface
Communication interface:
1 RJ45 10M/100M UTP network port 1 RJ45 RS-232 port 2 RS-485 port (Port B is reserved)
Alarm output:
4 relay outputs
General
Power supply:
5VDC/6A
Power consumption:
6W
Working temperature:
-10¡ãC ~ +55¡ãC
Working humidity:
10%~90%
Size:
360mm¡Á190mm¡Á55mm
Weight:
2.4Kg
Key Features £¦#8226; Manage up to 99 DVR units via network £¦#8226; Support DVR cascading via RS485 bus control mode £¦#8226; Multi-level keyboard user management £¦#8226; PTZ control by joystick £¦#8226; Receive and display DVR alarm information £¦#8226; 4 alarm outputs
